Cryogenic Tanks

Cryogenic stationary tanks are designed for the long-term storage of cryogenic liquefied gases under pressure. The inner tanks of medium and high pressure liquid gas storage tanks are made of cold-drawn austenitic stainless steel. These cryogenic tanks, which can be manufactured vertically and horizontally, can be used for LIN, LOX, LAR, LNG, CO2, and N2O.



Design Code EN 13458 – PED 2018/68/EU
Operating Pressure 5 – 39 Bar
Design Temperature -196°c / 50°c
Ambient Temperature -50°c / 55°c
Material - Inner Tank Stainless Steel (EN 10028-7)
Material - Outer Tank Carbon Steel (EN 10025/EN 10028-3)
Insulation Vacuum + Perlite

Above mentioned items are our standard products, please contact us for different sizes.
